EPSON TM-T20II POS receipt printer (002)

Epson Tm-T20Ii Pos Receipt Printer (002A0) Printer
Regular price K3,685.00

The TM-T20II is an affordable POS receipt printer with fast print speeds and economical features.

The combination of its fast print speeds, high reliability and economical operation, make this Energy Star-qualified printer a must-have for small retail and speciality stores, hospitality venues and grocery stores.

Features

  • Economical: Automatic paper reduction function
  • Reliable: Mechanism life of 15 million lines
  • Fast print speed: Print speed of 200mm/sec
  • Flexible connectivity: Two models: 1) USB + Serial 2) USB + Ethernet

SPECIFICATIONS

SKU: C31CD52002


Print type

Print method

  • Thermal line printing

Technology

  • Themal Line

Fonts & Styles

Print Speed

  • 200 mm/sec

Print Speed receipt

  • 200 mm/sec

Printing Font

  • ANK

Column capacity receipt

  • Paper width 80 mm, 48 / 64

Character set

  • 95 Alphanumeric, 18 set International, 128 x 43 Graphic

Characters per inch

  • 22.6 cpi / 16.9 cpi

Dot density

  • 203 DPI x 203 DPI

Colour Printing

  • Black

Printing Characters

  • Text (incl. Euro symbol), Graphics, Barcode

Paper

Paper Types

  • Receipt

Paper size roll paper

  • 79.50 ± 0.50 (W) mm x dia 83.00 mm,
  • 57.50 ± 0.50 (W) mm x dia 83.00 mm

Interfaces

Interfaces

  • RS-232, USB 2.0 Type B, Drawer kick-out

Data Buffer

Data Buffer

  • 4 kB or 45 Bytes

Power

Power Supply

  • PS-180 & UK AC cable

Power Consumption

  • Standby: 0.1 A, Mean: 1.8 A

Operating Voltage

  • 24 V

General

Product dimensions

  • 140‎ x 199 x 146 mm (Width x Depth x Height)

Product weight

  • 1.7 kg

Colour

  • Epson Dark Grey

Installation

  • horizontally, vertically, vertically with wall hanging bracket

Interface connectors

  • D.K.D. function (2 drivers)

Noise Level

  • Operation: 55 dB (A)

Humidity

  • Operation 10% - 90%, Storage 10% - 90%

Temperature

  • Operation 5° C - 45° C, Storage -10° C - 50° C

Reliability

Reliability

  • 60,000,000 MCBF (Lines), 360,000 MTBF (Hours)

Auto Cutter Life

  • 1,500,000 Cuts

Printer Life

  • 15,000,000 lines

Print Head Life

  • 100 km - 100,000,000 pulses

Standards Compliance

EMC Standards

  • FCC class A, CE marking, EN55022 Class A

Safety standards

  • UL, CSA, TÜV

Other Features

Cutter

  • Partial Cut

Sensors

  • Roll paper cover open sensor, Paper End Sensor

What's in the box

What's in the box

  • AC adapter,
  • C1,
  • CD Manual,
  • Main unit,
  • Paper roll spacer,
  • Power switch cover,
  • Roll paper,
  • Rubber feet,
  • Setup guide,
  • UK AC cable,
  • USB cable,
  • Wall hanging bracket,
  • Warranty document

Consumables and Accessories

  • OT-BZ20-634: OPTIONAL EXTERNAL BUZZER - C32C890634
