Canon i-SENSYS SME multi-function printer, offering speed, durability, quality and efficiency with mobile connectivity.
Reliable and easy-to-use multi-function printer for offices or SMEs with a multitude of functions.
SPECIFICATIONS
Machine type
- Mono Laser All-In-One
Available functions
- Print, Copy and Scan
Printer
Print speed
- Single sided : Up to 38 ppm (A4);
- Up to 63.1 ppm (A5-Landscape)
- Double sided : Up to 30.3 ipm (A4)
Printing method
- Monochrome laser beam printing
Print quality
- Up to 1200 x 1200 dpi
Print Resolution
- 600 x 600 dpi
Warm-up Time
- Approx. 14 seconds or less from power on
First Print Out Time
- Approx: 5.5 seconds or less
Printer Languages
- UFRII,
- PCL 5e1,
- PCL6
Fonts
- 45 PCL fonts,
- 136 PostScript fonts
Print margins
- 5 mm-top, bottom, left and right
- 10 mm-top, bottom, left and right (Envelope)
Toner saver mode
- Yes
Advanced printing features
- Secure Print
- Print from USB memory key (JPEG/TIFF/PDF)
- Google Cloud Print Ready
- iOS: AirPrint,
- Canon PRINT Business app
- Android;
- Mopria certified,
- Canon PRINT Business app
Copier
Copy Speed
- Single sided (A4): Up to 38 ppm
- Double sided (A4): Up to 30.3 ipm
First Copy Output Time (FCOT)
- ADF (A4): Approx. 6.6 seconds or less
- Platen (A4): Approx. 6.4 seconds or less
Copy resolution
- Up to 600 x 600 dpi
Copy modes
- Text,
- Text/Photo (Default),
- Text/Photo (High Quality),
- Photo
Double sided copying
- 2-sided to 2-sided (Automatic)
Multiple Copy
- Up to 999 copies
Reduction/Enlargement
- 25-400% in 1% increments
Other features
- Frame Erase, Collate, 2 on 1, 4 on 1, ID card copy
Scanner
Type
- Colour
Scan Resolution
- Optical: Up to 600 x 600 dpi
- Enhanced: Up to 9600 x 9600 dpi
Scan speed
- Single sided mono: 38ipm (300x600dpi)
- Single sided colour: 13ipm (300x600dpi)
- Double sided mono: 70ipm (300x600dpi)
- Double sided colour: 26ipm (300x600dpi)
Colour scanning depth
- 24 bit/24 bit (input/output)
Greyscales
- 256 levels
Compatibility
- TWAIN ,
- WIA,
- ICA
Max. scan width
- 216mm
Scan to E-mail / PC / USB memory key / FTP
- TIFF
- JPEG
- Compact PDF
- Searchable PDF
Scan to Cloud
- TIFF
- JPEG
- PNG5
iFAX
- ITU-T.37
Fax
Modem Speed
- 33.6 Kbps (Up to 3 seconds/page6)
Receive mode
- Fax only, Fax/Tel Auto Switch, Answer Mode, Manual
Fax resolution
- Standard: 200 x 100 dpi
- Fine: 200 x 200 dpi
- Super fine: 200 x 400 dpi
- Ultra fine: 400 x 400 dpi
FAX memory
- Up to 512 pages
Speed dials
- Up to 281 dials
Group dials/destinations
- Max. 299 dials / Max. 299 destinations
Sequential broadcast
- Max. 310 destinations
Memory backup
- Permanent fax memory backup (Backup with flash memory)
Double sided copying
- Yes (Transmit and Receive)
Other features
- Fax Forwarding,
- Dual Access,
- Remote Reception,
- PC Fax (TX only) DRPD,
- ECM,
- Auto Redial,
- Fax Activity Reports,
- Fax Activity Result Reports,
- Fax Activity Management Reports
Media Handling
Scanner Type
- Platen, 2-sided ADF (single pass)
Paper input (Standard)
- 250-sheet cassette
- 100-sheet multi-purpose tray
- 50-sheet ADF
Paper input (Option)
- 550-sheet cassette
Paper output
- 150-sheet
Media types
- Plain paper,
- Recycled paper,
- Heavy Paper,
- Thin paper,
- Label,
- Post card,
- Envelope
Media sizes
Cassette (Standard and optional):
- A4,
- A5,
- A5 (Landscape),
- A6,
- B5,
- Legal,
- Letter,
- Executive,
- Statement,
- OFFICIO,
- B-OFFICIO,
- M-OFFICIO,
- GLTR,
- GLGL,
- Foolscap,
- 16K,
- Custom sizes: Min. 105 x 148 mm Max. 215.9 x 355.6 mm.
- A4,
- A5,
- A5 (Landscape),
- A6,
- B5,
- Legal,
- Letter,
- Executive,
- Statement,
- OFFICIO,
- B-OFFICIO,
- M-OFFICIO,
- GLTR,
- GLGL,
- Foolscap,
- 16K,
- Indexcard,
- Envelope (COM10, Monarch, C5, DL),
- Custom sizes: Min 76.2 x 127 mm Max. 215.9 x 355.6 mm.
- A4,
- A5,
- A6,
- B5,
- Legal,
- Letter,
- Statement,
- Custom sizes: Min. 105 x 128 mm Max 215.9 x 355.6 mm
Media weights
- Cassette (standard and optional): 52 to 120 g/m²
- Manual purpose tray: 52 to 163 g/m²
- ADF: 50 to 105 g/m²
Double Sided Printing
- A4,
- Legal,
- Letter,
- OFFICIO,
- B-OFFICIO,
- M-OFFICIO,
- GLGL,
- Foolscap
- Custom size - Min. 210 x 279.4 mm Max. 215.9 x 355.6 mm
- 60 to 120 g/m2
Interface & Software
Interface type
- USB 2.0 Hi-Speed,
- 10BASE-T/100BASE-TX/1000Base-T,
- Wireless 802.11b/g/n,
- Wireless Direct Connection
Operating Systems Compatibility
- Windows® 10 / Windows® 8.1 / Windows® 7 / Server® 2016 / Server® 2012R2 / Server® 2012 / Server® 2008R2 / Server® 2008
- Mac OS X version 10.8.5 & up
- Linux
Network protocols
- LPD, RAW, Port9100, IPP, IPPS, WSD (IPv4,IPv6)
- Scan:
- Email, SMB, WSD-Scan(IPv4, IPv6), FTP-Scan, iFAX
- TCP/IP Application Services:
- Bonjour(mDNS), HTTP, HTTPS, POP before SMTP (IPv4,IPv6)
- DHCP, ARP+PING, Auto IP, WINS (IPv4)
- DHCPv6 (IPv6)
- Management:
- SNMPv1, SNMPv3 (IPv4,IPv6)
- Security (wired):
- IP/Mac address filtering, IEEE802.1X, SNMPv3, SSL (HTTPS, IPPS)
- Security (wireless):
- WEP(64/128 bit), WPA-PSK(TKIP/AES), WPA2-PSK(AES)
Software and printer management
- MF Scan Utility,
- Remote User Interface (RUI),
- Department ID Management,
- Toner Status Tool,
- iW Management Console: Server-based software for centralised management of a fleet of devices
- eMaintenance: embedded RDS allows remote eMaintenance services such as meter capture, automatic consumables management and remote diagnostics.
General features
Recommended Monthly Print Volume
- 750 - 4,000 pages per month
Duty cycle
- Max. 80,000 pages per month
Processor Speed
- 800MHz x 2
Memory
- 1GB
Control Panel
- 12.7 cm LCD Colour Touch Screen
Dimensions with trays (W x D x H)
- 453 mm x 464 mm x 392 mm
Installation Space (W x D x H)
- 682 mm x 1,083 mm x 895 mm
Weight
- Approx. 16.9 Kg
Operating Environment
- Temperature: 10 to 30ºC (50 to 86ºF)
- Humidity: 20 to 80% RH (no condensation)
Power Source
- 220-240V(±10%) 50/60Hz (±2Hz)
Power Consumption
- Maximum: Approx. 1,300 W
- Standby: Approx. 10 W
- Sleep mode: Approx. 0.9 W
- Typical Electricity Consumption (TEC): 1.2 kWh/week (230V)
Noise Levels
Consumables
Accessories / options
Items
- CST.Feeding Module-AH1 (550-sheet cassette)
Ready to make your mark on the world? Just type your text, edit with one-touch fast-formatting keys and print for perfect, professional labels every time.
With six font sizes, eight text styles and over 200 symbols to choose from, the LabelManager® 160 makes it easy to create high-quality labels for all your organization needs.
Plus, it’s compact and lightweight for portability, making it easy to label just about anything, anywhere.
To extend the battery life, the unit's auto power-off function turns the label maker off when not in use.
The Dymo LabelManager 160 puts the convenience of labeling in your hand. The labeler uses AAA batteries which are easy to replace and won't leave you searching for the charger. The LabelManager 160 features a large LCD that not only shows you the text itself, but also provides a preview of all text effects so you don't have to waste labels or guess what they will look like. The text can be customized using one of the 6 font sizes, 8 text styles, as well as 4 different boxes styles and underlining.
The keyboard's QWERTY layout is easy to use and provides a quick way to enter text. In addition to the alphabet keys, the LabelManager 160 provides multiple function buttons so you don't have to deal with cumbersome menus for basic operations. The interface includes dedicated number buttons, a button each for the symbols & currency menus, print, save, as well as other buttons.
FEATURES
- Creation of DYMO D1 labels with widths of 6 mm, 9 mm, 12 mm and in several colors
- Edit text easily with one-touch fast formatting keys - bold, italics, vertical, underline, boxed
- Type text quickly on the computer-style (QWERTY) keyboard
- Create labels with 6 font sizes, 8 text styles, 4 boxes plus underline, and 228 symbols and clip-art images
- Add professional impact and clarity to your labels with 228 symbols and clip-art images; use quick-access key to enter punctuation
- 36% fewer steps in order to create a label relative to the competition*
- See what your label will look like before you print - preview in the large LCD display
- Reprint last label, without retyping, using last-label memory feature
- Powered by 6 AAA batteries or optional AC-adapter
- Extend the battery life thanks to the automatic shut-off
- Optional power supply (sold separately)
SPECIFICATIONS
Type | Portable Tape Label Printer with Keyboard |
Maximum Printable Lines | 1 |
Printing Technology | Thermal Transfer |
Color Type | Black |
Special Functions | Auto Power Off, Reprint Last Label |
Number of Font Sizes | 6 |
Number of Styles | 4 (Box) 8 (Text) |
Built-In Symbols | 228 |
Tape Family | D1 |
Supported Tape Sizes | 0.24" / 6 mm, 0.35" / 9 mm, 0.47" / 12 mm |
Maximum Tape Length | 23' / 7 m |
Battery Type | 6 x AAA |
Dimensions | 8.0 x 4.7 x 1.9" / 203.0 x 118.0 x 49.0 mm |
Weight | 12.3 oz / 350 g |
Package Weight | 1.175 lb |
Box Dimensions (LxWxH) | 10.05 x 6.4 x 2.5" |
Package Includes
- Electronic label printer
- Quick start Guide
- LabelManager™ 160 Label Printer
- D1 Starter Label Cassette, Black on White 1/2" x 10'
- Quick Start Guide
- Batteries Not Included
With a large graphical display, fast-formatting keys and a long-lasting rechargeable battery, the LabelManager® 280 is your ticket to fast, uninterrupted labeling. The computer-style keyboard is perfect for typing text quickly, comfortably and easily. Plus, PC or Mac®*connectivity enables you to customize labels with fonts and graphics of your choosing from your computer. The LabelManager® 280 prints DYMO D1 labels in 1/4”, 3/8”, and 1/2” (6 mm, 9 mm, 12 mm) widths in a variety of colors – perfect for labeling your files, shelving, equipment and more.
Compatible Label Width: 1/4", 3/8", 1/2"
USB Connection: Yes
SKU: 1815990
Specifications
- Large screen and print preview.
- 6 different font sizes available, 8 different fonts, 4 different box styles, 220 symbols and clip-art images.
- Customize your labels with font styles and graphics from your computer with PC or Mac® connectivity.
- Use with DYMO Label ™ v.8 software *
- Customize labels with fonts and graphics on your computer through PC or Mac®* connection
- Enjoy a long-lasting rechargeable battery pack
- Type text quickly on the computer-style (QWERTY) keyboard
- Edit text easily with one-touch fast-formatting keys
- See font effects on screen before you print with a graphical display
Package Includes
- LabelManager 280 Label Maker
- Rechargeable Battery Pack
- USB Cable
- D1 Starter Label Cassette, Black on White 1/2" x 10'
- Quick Start Card and Quick Reference Guide
This compact 3-in-1 EcoTank with Wi-Fi Direct delivers on all fronts thanks to a sleek and compact design, mobile printing and efficient technology. This reliable cartridge-free printer features an enhanced ink filling system and easy to use ink bottles. Thanks to the included three years' worth of ink, you'll be able to save up to 90% on the cost of ink.
Ultra-low cost
Three whole years – that’s how long you could go without buying more ink for the L3150. This means it can save you up to 90% on the cost of ink. Giving you an extremely low cost per page, it produces up to 8,100 pages in black and 6,500 in colour with the included ink.
Cartridge-free printing
With the equivalent of up to 82 cartridges' worth of ink, you can go longer between refills with this EcoTank printer. It uses an ultra-high-capacity ink tank to completely remove the need for cartridges.
Discover the next generation
Thanks to the ink tank being positioned at the front of the printer, this new design is compact, provides easy access for refilling, and a clear view of the ink levels. It features an enhanced ink filling system engineered to minimise the risk of spills and mess. The new bottles incorporate a mechanism that ensures only the right tanks are filled with the corresponding colour.
Print from almost anywhere
With Wi-Fi and Wi-Fi Direct, your printer can receive documents to print from smart devices using the Epson iPrint app.
Quality results
With a Micro Piezo printhead, EcoTank provides a reliable printing solution. A one year warranty is provided as standard, while promotional warranties may offer more. Check the technical specification for the latest offer5.
Key Features
- Up to three years' worth of ink: Equivalent of up to 82 cartridges' worth of ink included
- Ultra-low-cost printing: Print up to 8,100 pages in black and 6,500 in colour
- Next generation ink filling system: Enjoy hassle and mess-free refills with the enhanced ink bottles
- Wi-Fi, Wi-Fi Direct & apps: Print from mobile devices
- 3-in-1: Print, copy & scan and borderless photo printing
Tech Specs
Technology
Printing Method
- Epson Micro Piezo™ print head
Nozzle Configuration
- 180 Nozzles Black, 59 Nozzles per Color
Minimum Droplet Size
- 3 pl, With Variable-Sized Droplet Technology
Ink Technology
- Dye Ink
Printing Resolution
- 5,760 x 1,440 DPI
Application
- Home, Home Office
All-in-One Functions
- Print, Scan, Copy
Printing Speed ISO/IEC 24734
- 10 pages/min Monochrome, 5 pages/min Colour
Printing Speed
- 33 pages/min Monochrome (plain paper 75 g/m²), 15 pages/min Colour (plain paper 75 g/m²), 69 Seconds per 10 x 15 cm photo (Epson Premium Glossy Photo Paper)
Scan
Single-sided scan speed (A4 black)
- 200 DPI; 11 sec. with flatbed scan
Single-sided scan speed (A4 colour)
- 200 DPI; 28 sec. with flatbed scan
Scanning Resolution
- 1,200 DPI x 2,400 DPI (Horizontal x Vertical)
Output formats
- BMP, JPEG, TIFF, PDF
Scanner type
- Contact image sensor (CIS)
Paper/Media Handling
Number of paper trays
- 1
Paper Formats
- A4,
- A6,
- A5,
- B5,
- 10 x 15 cm,
- 13 x 18 cm,
- 16:9,
- DL (Envelope),
- No. 10 (Envelope),
- C6 (Envelope),
- Letter,
- User defined,
- Legal
Duplex
- Manual
Output Tray Capacity
- 30 Sheets
Multifunction
- 100 Sheets Standard, 20 Photo Sheets
Media Handling
- Borderless print
General
Energy Use
- 12 Watt (standalone copying, ISO/IEC 24712 pattern),
- 0.7 Watt (sleep mode),
- 4.3 Watt (ready),
- 0.2 Watt (Power off)
Supply Voltage
- AC 100 V - 240 V
Product dimensions
- 375 x 347 x 179 mm (Width x Depth x Height)
Product weight
- 3.9 kg
Noise Level
- 6.5 B (A) with Epson Premium Glossy Photo Paper / Photo RPM mode - 52 dB (A) with Epson Premium Glossy Photo Paper / Photo RPM mode
Compatible Operating Systems
- Mac OS X 10.6.8 or later, Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP, Windows XP Professional x64 Edition
Included Software
- Epson Scan
Interfaces
- USB, WiFi, Wi-Fi Direct
WLAN Security
- WEP 64 Bit, WEP 128 Bit, WPA PSK (TKIP), WPA PSK (AES)
Mobile & Cloud printing services
- Epson Connect (iPrint, Email Print), Google Cloud Print
What's in the box
- 4 x 70ml individual ink bottles (Bk,C,Y,M) + 1 extra black ink bottle, Main unit, Power cable, Setup guide, Software (CD), Warranty document
Colour
- Black
Included Bottle Yield
Black yield
- 8,100 pages
Colour yield
- 6,500 pages
Ink and accessories
- Epson inks have been developed to work flawlessly with Epson printers to deliver crisp, smudge-proof text and vibrant photographic images that will last for generations. Find out what sets our inks apart from the competition.
103 ECOTANK BLACK INK BOTTLE - C13T00S14A
- 4,500 pages, 65.0 ml
103 ECOTANK CYAN INK BOTTLE - C13T00S24A
- 7,500 pages, 65.0 ml
103 ECOTANK MAGENTA INK BOTTLE - C13T00S34A
- 7,500 pages, 65.0 ml
103 ECOTANK YELLOW INK BOTTLE - C13T00S44A
- 7,500 pages, 65.0 ml
Fast, reliable and economical, the Epson LQ-2190 is a fast, flexible and reliable printing solution that achieves a perfect balance between large print volumes and first-class quality. Cost effective and dependable, this is ideal for producing invoices, delivery notes, inventory listings and labels.
Reliability and speed. This 24-pin wide carriage printer takes care of big print jobs without a fuss. You can rely on high quality results on a wide range of paper types while the impressive 576 cps (at 12 cpi) print speed is perfect for large volume tasks. This robust device is very dependable and has a print head life of 400 million strokes per wire, plus a meant time between failure of 20,000 power-on hours.
Flexibility. Choice of front, top, bottom and rear paper paths gives you even more control over desk space management. And the addition of a USB interface means more flexibility in connectivity.
Longer ribbon life. With a ribbon life of around 15 million characters, the ribbon replacement cycles are longer, which brings down running costs and maintenance time."
Pins
- 24 Pins
Printing Speed
-
LQ: 10 cpi: 120 chars/s, 12 cpi: 144 chars/s,
- HighSpeed-Draft: 10 cpi: 480 chars/s, 12 cpi: 576 chars/s,
- Draft: 10 cpi: 360 chars/s, 12 cpi: 432 chars/s
Carbon Copies
- 5 plus one original
Printing Resolution
- 360 x 180 DPI
Connectivity
Interfaces
- USB 2.0 Type B,
- Wired Network (optional),
- Type B interface,
- Bidirectional parallel,
- RS-232 (optional)
Paper / Media Handling
Document Feed
- Single sheet front and rear,
- Continuous paper front and rear,
- Paper output rear
Paper Formats
- Sheet Paper (single- and multi-layer),
- Continuous Paper (single- and multi-layer),
- Labels (single- and multi-layer),
- Roll Paper,
- Envelopes,
- Cardboard
General
Energy Use
- 46 Watt, 3 Watt (economy)
Product dimensions
- 693 x 405 x 268 mm (Width x Depth x Height)
Product weight
- 13 kg
Temperature
- Operation 5° C - 35° C
Humidity
- Operation 10% - 80%
Compatible Operating Systems
- Windows 2000, Windows 7, Windows 8, Windows 98, Windows Vista, Windows XP, Windows XP x64
Included Software
- Epson Status Monitor
Mean Time Between Failures
- 20,000 Hours
Print Head Life
- 400 Million Strokes/Wire
Sound Pressure
- Operation: 54 dB (A)
Memory
- 128 kB Included
Ribbon Yield
- 15,000,000 characters Black Draft
What's in the box
- Driver and utilities (CD),
- Main unit,
- Power cable,
- Ribbon,
- Setup guide,
- Software (CD),
- User manual (CD),
- Warranty document
Other Features
Emulations
- ESC/P2, IBM PPDS
RIBBONS AND ACCESSORIES
RIBBONS
Key Features
- Fast, reliable printing - Enjoy 24-pin quality up to A3 size and 576 cps
- Multi-part flexibility - Print up to 6-part forms (1 original + 5 copies)
- Paper handling - Choose from front, top, bottom, rear paper paths
- Print Speed Enhancer - For faster printing of bit images under Windows environment
- Easy connectivity - Parallel and USB interfaces as standard
SPECIFICATIONS
TECHNOLOGY
Printing Method
- Impact dot matrix
Number of Pins
- 24 pins
Number of columns
- 136 columns
RIBBONS
- EPSON SIDM BLACK RIBBON CARTRIDGE FOR LQ-2X70 / 2X80 / FX-2170 / 2180 (C13S015086) - 8 Million Chars
- EPSON SIDM BLACK RIBBON CARTRIDGE FOR LQ-2X70 / 2X80 / FX-2170 / 2180 (C13S015086BA) - 8 Million Chars
ACCESSORIES
- EPSON SIDM SERIAL I / F BOARD, NO BUFFER TYPE-B PLUG-IN CARD RS232D / 20MA - (C12C824432)
- EPSON SIDM PUSH / PULL TRACTOR UNIT FOR FX / LQ-2170 - (C12C800322)
- EPSON SIDM TYPE B EPSONNET 10 / 100 BASE TX INTERNAL PRINT SERVER 5 - (C12C824352)
- EPSON SIDM PAPER ROLL HOLDER FOR LX-300+II / 1170II, FX-890 / A, FX-2190, LQ-690 / 300+II SERIES - (C12C811141)
- SIDM EPSONNET 10 / 100 BASE TX INTERNAL PRINT SERVER PS107 - (1620202)
The TM-T20II is an affordable POS receipt printer with fast print speeds and economical features.
The combination of its fast print speeds, high reliability and economical operation, make this Energy Star-qualified printer a must-have for small retail and speciality stores, hospitality venues and grocery stores.
Features
- Economical: Automatic paper reduction function
- Reliable: Mechanism life of 15 million lines
- Fast print speed: Print speed of 200mm/sec
- Flexible connectivity: Two models: 1) USB + Serial 2) USB + Ethernet
SPECIFICATIONS
SKU: C31CD52002
Print type
Print method
- Thermal line printing
Technology
- Themal Line
Fonts & Styles
Print Speed
- 200 mm/sec
Print Speed receipt
- 200 mm/sec
Printing Font
- ANK
Column capacity receipt
- Paper width 80 mm, 48 / 64
Character set
- 95 Alphanumeric, 18 set International, 128 x 43 Graphic
Characters per inch
- 22.6 cpi / 16.9 cpi
Dot density
- 203 DPI x 203 DPI
Colour Printing
- Black
Printing Characters
- Text (incl. Euro symbol), Graphics, Barcode
Paper
Paper Types
- Receipt
Paper size roll paper
- 79.50 ± 0.50 (W) mm x dia 83.00 mm,
- 57.50 ± 0.50 (W) mm x dia 83.00 mm
Interfaces
Interfaces
- RS-232, USB 2.0 Type B, Drawer kick-out
Data Buffer
Data Buffer
- 4 kB or 45 Bytes
Power
Power Supply
- PS-180 & UK AC cable
Power Consumption
- Standby: 0.1 A, Mean: 1.8 A
Operating Voltage
- 24 V
General
Product dimensions
- 140 x 199 x 146 mm (Width x Depth x Height)
Product weight
- 1.7 kg
Colour
- Epson Dark Grey
Installation
- horizontally, vertically, vertically with wall hanging bracket
Interface connectors
- D.K.D. function (2 drivers)
Noise Level
- Operation: 55 dB (A)
Humidity
- Operation 10% - 90%, Storage 10% - 90%
Temperature
- Operation 5° C - 45° C, Storage -10° C - 50° C
Reliability
Reliability
- 60,000,000 MCBF (Lines), 360,000 MTBF (Hours)
Auto Cutter Life
- 1,500,000 Cuts
Printer Life
- 15,000,000 lines
Print Head Life
- 100 km - 100,000,000 pulses
Standards Compliance
EMC Standards
- FCC class A, CE marking, EN55022 Class A
Safety standards
- UL, CSA, TÜV
Other Features
Cutter
- Partial Cut
Sensors
- Roll paper cover open sensor, Paper End Sensor
What's in the box
What's in the box
- AC adapter,
- C1,
- CD Manual,
- Main unit,
- Paper roll spacer,
- Power switch cover,
- Roll paper,
- Rubber feet,
- Setup guide,
- UK AC cable,
- USB cable,
- Wall hanging bracket,
- Warranty document
Devote more time to customer service by trusting your point of service to this world leading thermal receipt printer
SPECIFICATIONS
SKU: C31C636322
Print type
Print method
- Thermal line printing
Technology
- Themal Line
Fonts & Styles
Print Speed
- 200 mm/sec
Column capacity receipt
- Paper width 80 mm, 56 / 42
Character size
- 0.99 mm (W) x 2.4 mm (H) / 1.41 mm (W) x 3.39 mm (H)
Character set
- 95 Alphanumeric, 48 International, 128 x 11 Graphic
Characters per inch
- 20 cpi / 15 cpi
Dot density
- 180 DPI x 180 DPI
Colour Printing
- Two Colors
Paper
Paper Types
- Receipt
Paper size roll paper
- 79.50 ± 0.50 (W) mm x dia 83.00 mm,
- 57.50 ± 0.50 (W) mm x dia 83.00 mm (option)
Interfaces
Interfaces
- Drawer kick-out, Powered USB
Power
Power Supply
- PS-180 (option)
Power Consumption
- Standby: 0.1 A, Mean: 1.8 A
Operating Voltage
- 24 V
General
Product dimensions
- 145 x 195 x 148 mm (Width x Depth x Height)
Product weight
- 1.8 kg
Colour
- Epson Dark Grey
Installation
- horizontally, vertically with wall hanging bracket
Interface connectors
- D.K.D. function (2 drivers)
Noise Level
- Operation: 55 dB (A)
Humidity
- Operation 10% - 90%, Storage 10% - 90%
Temperature
- Operation 5° C - 45° C, Storage -10° C - 50° C
Reliability
Reliability
- 52,000,000 MCBF (Lines), 360,000 MTBF (Hours)
Auto Cutter Life
- 1,500,000 Cuts
Printer Life
- 15,000,000 lines
Print Head Life
- 100 km - 100,000,000 pulses
Standards Compliance
EMC Standards
- CE marking
Safety standards
- TÜV
Other Features
Changeable interface
- Yes
Cutter
- Partial Cut
Sensors
- Paper End Sensor, Paper Near End Sensor, Cover Open Sensor
What's in the box
What's in the box
- Connector Cover,
- Main unit,
- Power switch cover,
- User manual
Consumables and Accessories
- WH-10 (040) WALL HANGING BRACKET - C32C845040
- PS-180: UNIVERSAL POWER SUPPLY - C32C825341
- EPSON OT-BX88 - C32C814594
- EPSON UB-P02II - C32C823891
- UB-S01 - C32C823361
- UB-S09 - C32C823861
- UB-U01III - C32C824111
- UB-U02III - C32C824121
- UB-U03II - C32C824131
- UB-U04 - C32C823950
- UB-U05 - C32C823991
- UB-U06 - C32C824071
- UB-U09 - C32C823893
- UB-U19 -C32C824092
- EPSON AC CABLE, UK CABLE - 2093752
- UB-E04: 10 / 100 BASET ETHERNET I / F BOARD - C32C881008
SKU: C31C514057A0
Tech Specs
Print type
Print method
- 9-pin serial impact dot matrix
Technology
- Serial Impact Dot Matrix
Fonts & Styles
Print Speed
- 4.70 lps (40 columns, 16.00 cpi)
Column capacity receipt
- Paper width 76 mm, 33 / 40
Character size
- 1.2 mm (W) x 3.1 mm (H) / 1.6 mm (W) x 3.1 mm (H)
Character set
- 95 Alphanumeric, 48 International, 128 x 12 Graphic
Characters per inch
- 13.3 cpi / 16 cpi
Colour Printing
- Two colours
Paper
Paper Types
- Receipt
Copy capability receipt
- one copies plus one original
Paper size roll paper
- 76.00 ± 0.50 (W) mm x dia 83.00 mm,
- 69.50 ± 0.50 (W) mm x dia 83.00 mm,
- 57.50 ± 0.50 (W) mm x dia 83.00 mm
Interfaces
Interfaces
- Drawer kick-out, Bidirectional Parallel
Power
Power Supply
- AC adapter, C
Operating Voltage
- 24 V
General
Product dimensions
- 160 x 248 x 139 mm (Width x Depth x Height)
Product weight
- 2.5 kg
Colour
- Epson Dark Gray
Installation
- horizontally, vertically with wall hanging bracket
Interface connectors
- D.K.D. function (2 drivers)
Noise Level
- Operation: 64 dB (A)
Supported Humidity
- Operation 10% - 90%, Storage 10% - 90%
Supported Temperature
- Storage -10° C - 50° C
Reliability
Reliability
- 18,000,000 MCBF (Lines), 180,000 MTBF (Hours)
Auto Cutter Life
- 800,000 Cuts
Printer Life
- 7,500,000 lines
Standards Compliance
EMC Standards
- CE marking
Safety standards
- TÜV
Other Features
Changeable interface
- Yes
Cutter
- Partial Cut
Sensors
- Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
What's in the box
What's in the box
- AC adapter, C, Main unit, Ribbon, Roll paper, User manual
Ribbons
- Epson ERC38BR Ribbon Cartridge black/red
SKU: C31C514057A0
Tech Specs
Print type
Print method
- 9-pin serial impact dot matrix
Technology
- Serial Impact Dot Matrix
Fonts & Styles
Print Speed
- 4.70 lps (40 columns, 16.00 cpi)
Column capacity receipt
- Paper width 76 mm, 33 / 40
Character size
- 1.2 mm (W) x 3.1 mm (H) / 1.6 mm (W) x 3.1 mm (H)
Character set
- 95 Alphanumeric, 48 International, 128 x 12 Graphic
Characters per inch
- 13.3 cpi / 16 cpi
Colour Printing
- Two colours
Paper
Paper Types
- Receipt
Copy capability receipt
- one copies plus one original
Paper size roll paper
- 76.00 ± 0.50 (W) mm x dia 83.00 mm,
- 69.50 ± 0.50 (W) mm x dia 83.00 mm,
- 57.50 ± 0.50 (W) mm x dia 83.00 mm
Interfaces
Interfaces
- Drawer kick-out, USB 1.1 Type B
Power
Power Supply
- AC adapter, C
Operating Voltage
- 24 V
General
Product dimensions
- 160 x 248 x 139 mm (Width x Depth x Height)
Product weight
- 2.5 kg
Colour
- Epson Dark Gray
Installation
- horizontally, vertically with wall hanging bracket
Interface connectors
- D.K.D. function (2 drivers)
Noise Level
- Operation: 64 dB (A)
Supported Humidity
- Operation 10% - 90%, Storage 10% - 90%
Supported Temperature
- Storage -10° C - 50° C
Reliability
Reliability
- 18,000,000 MCBF (Lines), 180,000 MTBF (Hours)
Auto Cutter Life
- 800,000 Cuts
Printer Life
- 7,500,000 lines
Standards Compliance
EMC Standards
- CE marking
Safety standards
- TÜV
Other Features
Changeable interface
- Yes
Cutter
- Partial Cut
Sensors
- Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
What's in the box
What's in the box
- AC adapter, C, Main unit, Ribbon, Roll paper, User manual
Ribbons
- Epson ERC38BR Ribbon Cartridge black/red
SKU: C31C514057BE
Tech Specs
Print type
Print method
- 9-pin serial impact dot matrix
Technology
- Serial Impact Dot Matrix
Fonts & Styles
Print Speed
- 4.70 lps (40 columns, 16.00 cpi)
Column capacity receipt
- Paper width 76 mm, 33 / 40
Character size
- 1.2 mm (W) x 3.1 mm (H) / 1.6 mm (W) x 3.1 mm (H)
Character set
- 95 Alphanumeric, 48 International, 128 x 12 Graphic
Characters per inch
- 13.3 cpi / 16 cpi
Colour Printing
- Two colours
Paper
Paper Types
- Receipt
Copy capability receipt
- one copies plus one original
Paper size roll paper
- 76.00 ± 0.50 (W) mm x dia 83.00 mm,
- 69.50 ± 0.50 (W) mm x dia 83.00 mm,
- 57.50 ± 0.50 (W) mm x dia 83.00 mm
Interfaces
Interfaces
- Drawer kick-out, Wired Network
Power
Power Supply
- AC adapter, C
Operating Voltage
- 24 V
General
Product dimensions
- 160 x 248 x 139 mm (Width x Depth x Height)
Product weight
- 2.5 kg
Colour
- Epson Dark Gray
Installation
- horizontally, vertically with wall hanging bracket
Interface connectors
- D.K.D. function (2 drivers)
Noise Level
- Operation: 64 dB (A)
Supported Humidity
- Operation 10% - 90%, Storage 10% - 90%
Supported Temperature
- Storage -10° C - 50° C
Reliability
Reliability
- 18,000,000 MCBF (Lines), 180,000 MTBF (Hours)
Auto Cutter Life
- 800,000 Cuts
Printer Life
- 7,500,000 lines
Standards Compliance
EMC Standards
- CE marking
Safety standards
- TÜV
Other Features
Changeable interface
- Yes
Cutter
- Partial Cut
Sensors
- Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
What's in the box
What's in the box
- AC adapter, C, Main unit, Ribbon, Roll paper, User manual
Ribbons
- Epson ERC38BR Ribbon Cartridge black/red
This fits the bill when you need fast, reliable multi-part printing for receipts, journals and slips
Specifications
Print type
Print method
- 9-pin serial impact dot matrix
Technology
- Serial Impact Dot Matrix
Fonts & Styles
Print Speed
- 311 / 233 cps
Column capacity receipt
- Paper width 69.5 mm, 30 / 40
Column capacity slip
- 66 cps / 88 cps
Character size
- 1.6 mm (W) x 3.1 mm (H) / 1.3 mm (W) x 3.1 mm (H)
Character set
- 95 Alphanumeric, 32 International, 128 x 9 Graphic
Characters per inch
- 16.7 cpi / 12.5 cpi
Paper
Paper Types
- Journal, Receipt, Slip
Copy capability slip
- four copies plus one original
Paper size roll paper
- 69.50 ± 0.50 (W) mm x dia 83.00 mm
Paper size slip
- 70 - 210 mm (W) x 70 - 297 mm (H)
Interfaces
Interfaces
- Drawer kick-out, Bidirectional parallel
Power
Power Supply
- PS-180 (option)
Power Consumption
- Standby: 0.3 A, Mean: 1.8 A
Operating Voltage
- 24 V
General
Product dimensions
- 251 x 298 x 195 mm (Width x Depth x Height)
Product weight
- 5.6 kg
Colour
- Epson Cool White
Installation
- horizontally
Interface connectors
- D.K.D. function (2 drivers)
Noise Level
- Operation: 63 dB (A)
Humidity
- Operation 30% - 80%, Storage 30% - 90%
Temperature
- Operation 5° C - 40° C, Storage -10° C - 50° C
Reliability
Reliability
- 18,000,000 MCBF (Lines), 180,000 MTBF (Hours)
Printer Life
- 7,500,000 lines
Ribbon life slip
- 4,500,000 characters
Print Head Life
- 150 Mio Characters
Standards Compliance
EMC Standards
- CE marking
Safety standards
- TÜV
Other Features
Cutter
- Partial Cut
Factory options
- MICR device
Sensors
- Cover Open Sensor,
- Slip eject sensor,
- Journal near-end sensor,
- Receipt near-end sensor,
- Journal paper sensor,
- Receipt paper sensor,
- Slip insertion sensor
What's in the box
What's in the box
- Main unit,
- Paper roll take-up reel,
- Power switch cover,
- Ribbon,
- Roll paper,
- User manual
Get a fast and energy-efficient printer that delivers vibrant, top-quality colour documents.
SPECIFICATIONS
Functions
Printer page yield
- Declared yield value in accordance with ISO/IEC 19798. Actual yields vary considerably based on images printed and other factors. For more information, visit http://www.hp.com/go/learnaboutsupplies
First page out (ready) black
- As fast as 6 sec
First page out (ready) color
- As fast as 7 sec
Resolution (black)
- HP ImageREt 3600
Resolution (color)
- HP ImageREt 3600
Resolution technology
- HP ImageREt 3600, Pantone Calibrated
Monthly duty cycle
- Up to 80,000 pages
Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other HP LaserJet or HP Color LaserJet devices, and enables appropriate deployment of printers and MFPs to satisfy the demands of connected individuals or groups.
Recommended monthly page volume
- 2,000 to 6,000 pages
Print Technology
- Laser
Display
- 4-line LCD (color graphics) with 10-key pad
Processor speed
- 1.2 GHz
Number of print cartridges
- 4 (1 each black, cyan, magenta, yellow)
Replacement cartridges
- HP 508A Black LaserJet Toner Cartridge (~6000 ISO yield) CF360A;
- HP 508X Black LaserJet Toner Cartridge (~12,500 ISO yield) CF360X;
- HP 508A Cyan LaserJet Toner Cartridge (~5000 ISO yield) CF361A;
- HP 508X Cyan LaserJet Toner Cartridge (~9500 ISO yield) CF361X;
- HP 508A Yellow LaserJet Toner Cartridge (~5000 ISO yield) CF362A;
- HP 508X Yellow LaserJet Toner Cartridge (~9500 ISO yield) CF362X;
- HP 508A Magenta LaserJet Toner Cartridge (~5000 ISO yield) CF363A; HP 508X Magenta LaserJet Toner Cartridge (~9500 ISO yield) CF363X
Print languages
- HP PCL 6;
- HP PCL 5c;
- HP postscript level 3 emulation,
- native PDF printing (v 1.7)
Automatic paper sensor
- Yes
Paper trays, standard
- 2
Paper trays, maximum
- 5
Mobile Printing Capability
- HP ePrint;
- Apple AirPrint™;
- Mopria™-certified
Connectivity, standard
- Hi-Speed USB 2.0 port;
- Built-in Fast Ethernet 10/100/1000Base-TX network port
Connectivity, optional
- HP Jetdirect 3000w NFC/Wireless Accessory J8030A (late availability),
- HP Jetdirect 2900nw Print Server J8031A (late availability)
Network ready
- Standard (built-in Gigabit Ethernet)
Ports
- 2 Hi-Speed USB 2.0 Host;
- 1 Hi-Speed USB 2.0 Device;
- 1 Gigabit/Fast Ethernet 10/100/1000Base-TX; HIP (Hardware Integration Pocket)
Security management
- Management security: SNMPv3, SSL/TLS,
- WPA2-Enterprise,
- 802.1X authentication (EAP- PEAP, EAP-TLS),
- IPP over TLS,
- IPsec/Firewall with Certificate,
- Pre-Shared Key Authentication, and Kerberos Authentication;
- Support for WJA-10 IPsec Configuration using IPsec Plug-in; access port for Kensington-style lock
Minimum system requirements
- Mac OS X 10.7 Lion, OS X 10.8 Mountain Lion, OS X 10.9 Mavericks, OS X 10.10 Yosemite;
- Internet;
- USB;
- 1 GB available hard disk
- Windows XP (SP3) all 32-bit editions (XP Home, XP Pro, etc.), Windows Vista all 32-bit editions (Home Basic, Premium, Professional, etc.), Windows 7 all 32-bit and 64-bit editions, Windows 8/8.1 all 32-bit and 64-bit editions (excluding RT OS for Tablets), Windows 10 all 32-bit and 64-bit editions (excluding RT OS for Tablets); Windows OS compatible with Universal Print Driver (From HP.com): Windows XP SP3 32-bit and 64-bit editions (XP Home, XP Pro, etc.), Windows Vista all 32-bit and 64-bit editions (Home Basic, Premium, Professional, etc.), Windows 7 all 32-bit and 64-bit editions, Windows 8/8.1 all 32-bit and 64-bit editions (excluding RT OS for Tablets), Windows 10 all 32-bit and 64-bit editions (excluding RT OS for Tablets);
- Mobile OS (In-OS drivers): iOS, Android, Windows 8/8.1/10 RT;
- Linux OS (In-OS HPLIP): SUSE Linux (12.2, 12.3, 13.1), Fedora (17, 18, 19, 20), Linux Mint (13, 14, 15, 16, 17), Boss (3.0, 5.0), Ubuntu (10.04, 11.10, 12.04, 12.10, 13.04, 13.10, 14.04, 14.10), Debian (6.0.x, 7.x), Other OS: UNIX;
- CD-ROM or DVD drive, or Internet connection;
- Dedicated USB or network connection or Wireless connection;
- 200 MB available hard disk space
Compatible operating systems
- Windows OS compatible with In-Box Driver: Windows XP (SP3) all 32-bit editions (XP Home, XP Pro, etc.), Windows Vista all 32-bit editions (Home Basic, Premium, Professional, etc.), Windows 7 all 32-bit and 64-bit editions, Windows 8/8.1 all 32-bit and 64-bit editions (excluding RT OS for Tablets), Windows 10 all 32-bit and 64-bit editions (excluding RT OS for Tablets);
- Windows OS compatible with Universal Print Driver (From HP.com): Windows XP SP3 32-bit and 64-bit editions (XP Home, XP Pro, etc.), Windows Vista all 32-bit and 64-bit editions (Home Basic, Premium, Professional, etc.), Windows 7 all 32-bit and 64-bit editions, Windows 8/8.1 all 32-bit and 64-bit editions (excluding RT OS for Tablets), Windows 10 all 32-bit and 64-bit editions (excluding RT OS for Tablets);
- Mac OS (HP Print Drivers available from HP.com and Apple Store): OS X 10.7 Lion, OS X 10.8 Mountain Lion, OS X 10.9 Mavericks, OS X 10.10 Yosemite;
- Mobile OS (In-OS drivers): iOS, Android, Windows 8/8.1/10 RT;
- Linux OS (In-OS HPLIP): SUSE Linux (12.2, 12.3, 13.1), Fedora (17, 18, 19, 20), Linux Mint (13, 14, 15, 16, 17), Boss (3.0, 5.0), Ubuntu (10.04, 11.10, 12.04, 12.10, 13.04, 13.10, 14.04, 14.10), Debian (6.0.x, 7.x), Other OS: UNIX
Memory card compatibility
- No
Memory, standard
- 1 GB
Memory, maximum
- 2 GB
Printer management
- Printer Administrator Resource Kit (Driver Configuration Utility, Driver Deployment Utility,
- Managed Printing Administrator);
- HP Web JetAdmin Software;
- HP Proxy Agent Software;
- HP Imaging and Printing Security Center;
- HP Utility (Mac)
Print speed, color (draft)
- Measured using ISO/IEC 24734, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Supported network protocols
- IPv4/IPv6: Apple Bonjour Compatible (Mac OS 10.2.4 or higher),
- SNMPv1/v2c/v3,
- HTTP,
- HTTPS,
- FTP,
- TFTP,
- Port 9100,
- LPD,
- WS Discovery,
- IPP,
- Secure-IPP,
- IPsec/Firewall; IPv6: DHCPv6,
- MLDv1,
- ICMPv6; IPv4: Auto-IP,
- SLP,
- Telnet,
- IGMPv2,
- BOOTP/DHCP,
- WINS,
- IP Direct Mode,
- WS Print;
- Other: NetWare NDS,
- Bindery,
- NDPS,
- ePrint
Hard disk
- Optional
Paper handling input, standard
- 100-sheet multipurpose tray,
- 550-sheet input tray 2
Paper handling output, standard
- 250-sheet output bin
Duplex printing
- Automatic (standard)
Finished output handling
- Sheetfed
Media sizes supported
- Tray 1: A4, RA4, A5, B5 (JIS), B6 (JIS), 10 x 15 cm, A6, 16K, envelopes (B5, C5 ISO, C6, DL ISO); Custom: 76 x 127 to 216 x 356 mm;
- Tray 2: A4, A5, B5 (JIS), B6 (JIS), 10 x 15 cm, A6, 16K; Custom: 102 x 148 to 216 x 297 mm; Optional Trays 3+: A4, RA4, A5, B5 (JIS), 16K; Custom: 102 x 148 to 216 x 356 mm
Media sizes, custom
- Tray 1: 3 x 5 to 8.5 x 14 in;
- Tray 2: 4.0 x 5.85 to 8.5 x 11.69 in;
- Optional Trays 3+: 4.0 x 5.85 to 8.5 x 14 in
Media types
- Paper (plain, light, bond,
- recycled,
- mid-weight,
- heavy,
- mid-weight glossy,
- heavy glossy,
- extra heavy,
- extra heavy glossy,
- cardstock,
- card glossy) color transparency,
- labels,
- letterhead,
- envelope,
- preprinted,
- prepunched,
- colored,
- rough,
- opaque film,
- user-defined
Supported media weight
- Tray 1: 16 to 58 lb (plain); 28 to 58 lb (glossy);
- Tray 2: 16 to 58 lb (plain paper); 28 to 58 lb (glossy paper);
- Optional Trays 3+: 16 to 58 lb (plain paper); 28 to 58 lb (glossy paper);
- Automatic Duplexer: 16 to 43 lb
Media weights by paper path
- Tray 1: 60 to 220 g/m² (plain paper), 105 to 220 g/m² (glossy paper);
- Tray 2: 60 to 220 g/m² (plain paper), 105 to 220 g/m² (glossy paper);
- Optional Trays 3+: 60 to 220 g/m² (plain paper), 105 to 220 g/m² (glossy paper);
- Automatic Duplexer: 60 to 163 g/m²
Power
- Input voltage: Input voltage: 200 to 240 VAC, 50 Hz
Print speed, black (normal)
- Up to 40 ppm
Power consumption
- 617 watts (Active Printing),
- 33.7 watts (Ready),
- 3.95 watts (Sleep),
- 1 watt (Auto-Off/wake on LAN),
- 0.1 watts (Auto-Off/Manual On),
- 0.1 watts (Off)
Power consumption in Auto-Off mode depends on customer network switch capability, user configuration and network activity. Off-mode power may vary while checking network packets for print jobs.
Energy efficiency
- ENERGY STAR® qualified,
- CECP,
- EPEAT® Silver,
- Taiwan Green Mark
Operating temperature range
- 59 to 81ºF
Operating humidity range
- 30 to 70% RH
Dimensions (W X D X H)
- 18 x 18.9 x 15.7 in
Dimensions Maximum (W X D X H)
- 27.5 x 18.9 x 15.7 in
Weight
- 60.6 lb
Package weight
- 69 lb
What's in the box
- Printer; Four preinstalled HP LaserJet toner cartridges (yield ~6000 pages black and ~5000 pages color);
- Toner collection unit;
- In-box documentation;
- Software CD;
- Power Cord;
- 100-sheet multipurpose tray 1;
- 550-sheet input tray 2
Print speed, color (normal)
- Up to 40 ppm
Cable included
- No, please purchase USB cable separately
Software included
- Windows OS: HP Software Installer/Uninstaller,
- HP PCL 6 Printer Driver,
- HP Device Experience (DXP),
- HP Update,
- Product Registration Assist,
- HP Web Services Assist (HP Connected),
- Online user manuals; Mac OS: Welcome Screen, (Directs users to HP.com or OS App Store for LaserJet Software)
FCC
- FCC Class A emissions - for use in commercial environments, not residential environments
