The Magellan™ 3200VSi bar code reader delivers imaging technology in a compact, vertical form factor

The Magellan™ 3200VSi bar code reader brings imaging technology to retailers that require high performance in a compact, vertical form factor. Its imaging technology provides outstanding performance when capturing hard-to-read bar codes such as truncated (short), out-of-spec, poorly printed and GS1 DataBar™ codes and provides support for both linear (1D) and 2D label decoding. The Magellan 3200VSi imager enables both sweep and presentation scanning techniques ensuring maximum productivity and ergonomic ease.

A unique included feature is a Micro-SD card reader to help with software management, upgrading and maintenance. Most of the 3200VSi scanner features are software-based allowing new capabilities to be added, even after the initial installation.

FeaturesHoneywell MK9540-37A38 Barcode Scanner is a single-line laser scanners feature patented automatic infrared activation and can decode all standard 1D barcodes, including GS1 DataBar (formerly known as RSS codes). Use the scanner either as a handheld device or a fixed presentation scanner when mounted in the stand. Use the scanner either as a handheld device or a fixed presentation scanner when mounted in the stand. Uniting form with function, the Voyager series has become the industry benchmark for value and performance. Zero in on desired code and complete data transmission with the push of a single button – ideal for menu scanning applications (MS9540 only). For presentation scanning, Honeywell offers a stand with automatic in-stand detection technology.

FEATURES

SPECIFICATIONS

Mechanical
Dimensions (LxWxH)

• 198 mm x 78 mm x 56 mm (7.8 ̋ x 3.1 ̋ x 2.2 ̋)

Weight

• 149 g (5.3 oz)

Input Voltage

• 5 VDC + 0.25 V

Operating Power

• 825 mW (165 mA @ 5 V)

Standby Power

• 600 mW (120 mA @ 5 V)

Host System Interfaces

• USB, RS232, Keyboard Wedge, IBM 46xx (RS485), OCIA, Laser Emulation, Light Pen Wand Emulation

Operating Temperature

• 0°C to 40°C (32°F to 104°F)

Storage Temperature

• -40°C to 60°C (-40°F to 140°F)

Humidity

• 5% to 95% relative humidity, non-condensing

Drop

• Designed to withstand 1.5 m (5’) dropsvironmental Sealing

Sealed to resist airborne particulate contaminants

Light Levels

• 4842 Lux

Scan Pattern

• Single scan line

Scan Speed

• 72 scan lines per second

Scan Angle

• Horizontal: 50°

Print Contrast

• 35% minimum reflectance difference

Pitch, Skew

• 68°, 52°

Decode Capabilities

• Reads standard 1D and GS1 DataBar symbologies

With over eight million sold, the LS2208 remains our best selling handheld laser scanner. The LS2208 has it all — enterprise class scanning in a very ergonomic and durable lightweight design that delivers all day comfort, an extra-long read range for easy scanning, plus support for everyday 1D bar codes, including high-density. With multiple interfaces, a universal cable and support for keyboards in 97 languages, the LS2208 delivers plug-and-play simplicity in virtually every corner of the world. The LS2208 — the well-proven scanner powering the checkout lines all around the world.

SPECIFICATIONS

Durable construction

With its patented single board construction, patented frictionless liquid polymer scan element, scratch resistant tempered glass exit window and a stringent drop and tumble specification, the LS2208 delivers reliable all-day, every day operation.

Capture high-density bar codes for greater application flexibility

With just one scanner, you can capture the high density bar codes common on small items.

Deploy in every corner of the world

With support for 97 international keyboards, the LS2208 is ready for operation in your country, right out of the box.

Class-leading working range

Workers can capture everyday 13 mil UPC bar codes on items that are over 25 in./63.5 cm away, improving productivity and the customer checkout experience.

More decode feedback options

Choose from a variety of options to indicate the successful capture of a bar code: the Direct Decode Indicator (a blinking laser line), a beep tone, a red/green LED indicator — or any combination of the three.

All day comfort your workers can count on

The well-proven ergonomic and lightweight balanced design provides maximum comfort, even in the most scan intensive environments. The result? Reduced user fatigue and increased worker productivity.

Flexible handheld or hands-free operation

The optional IntellistandTMenables presentation scanning and allows workers to automatically switch between hands-free and handheld modes in the time it takes to drop the LS2208 into the stand.

Multiple interfaces

No matter what host you need to connect to today or tomorrow, the future proof LS2208 is ready.

Truly plug-and-play

The universal cable connects to any computing environment, practically eliminating setup and training time.

Advanced Data Formatting (ADF)

Format data properly before it is sent to your host computer, eliminating the costly modification of host software.
