Cabinets/Racks
FEATURED PRODUCTS - Cabinets/Racks
The 12U Fixed Wallmount Cabinet is a simple, cost-effective way to mount 12U rackmount equipment.
- 120 lbs Maximum Capacity
- Form Factor 12U
- Width: 18"
- Depth: 37"
- Length: 20"
Attractive, secure fixed wall mount rack cabinet is a cost effective unit. Mounts in minutes, allows you to install rackmount equipment and cables easily and quickly. Fixed wall mount rack has a glass front so you can quickly monitor your installation. This cabinet is perfect for almost any wiring room. With its generous 20 inch deep chassis, and 150 lb weight capacity, this cabinet is perfect for CAT5, Fiber, Voice, or almost any cabling need.
Features
- Standard 19" width
- 550 x 450 mm
- Front Glass Door with Lock, Side doors Openable
- Removable side panels allows fast access to cable installation and routing.
- Supports over 150 lbs.
- 1 set of universal square rails, adjustable
- Top knockout for 4.5" fan
- 2 cable slots in top and bottom
- 450 mm maximum mounting depth
- Optional caster base to turn into portable floor cabinet.
- 53 CFM ultra quiet fan kit is an option.
Note: Wall Mounted Rack comes with 20 cage nuts additional mounting hardware if required can be purchased separately
Feautures
- Double section welded frame structure;
- Easy operation and maintaining at the back;
- 19” standard installation;
- Removable side panels, side locks are optional, easy installing and maintaining;
- Cable entry at the top cover and bottom panel;
- 120mm fan optional;
- Turning angle of front door is above 180 degrees;
- Turning angle of rear door is above 90 degrees;
Main material
- SPCC cold rolled steel;
- Thickness:mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm.
Surface finish
- Degreasing, pickling, phosphoric, powder coated
Degree of protection
- IP20
Loading capacity
- Static loading: 60KG
Standards
- Complies with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、DIN41494;PART7, ETSI standard.
Features
- Front door , made of glass , with silk-screened flower pattern;
- Wall mounting installation;
- Easy mounting installation(Patent)
- 10” or 19” standard installation;
- Accessory parts are installed in the cabinet according to demand;
- Cable entry on both of top cover and bottom panel;
- Turning angle of front door is over 180 degrees.
Main Material
- SPCC cold rolled steel
- Thickness:Mounting profile: 1.5mm, others: 0.8mm.
Surface Finish
- Degreasing, pickling, phosphoric, powder coated
Degree of Protection
- IP20
Loading Capacity
- Static loading: 30KG
Standards
- Complies with ANSI/EIA RS-310-D, IEC297-2, DIN41494, PART1、DIN41494, PART7 ETSI standard.
