Feautures

• Double section welded frame structure;
• Easy operation and maintaining at the back;
• 19” standard installation;
• Removable side panels, side locks are optional, easy installing and maintaining;
• Cable entry at the top cover and bottom panel;
• 120mm fan optional;
• Turning angle of front door is above 180 degrees;
• Turning angle of rear door is above 90 degrees;

 Main material

• SPCC cold rolled steel;
• Thickness：mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm.

Surface finish

• Degreasing, pickling, phosphoric, powder coated

Degree of protection

• IP20

 Loading capacity

• Static loading: 60KG

Standards

• Complies with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、DIN41494;PART7, ETSI standard.
